Electrotherm Transformer Division



Infrastrucutre

Production
Testing


Production

Plant Location: Palodiya Village
Plant is capable of producing and testing transformers up to 50 MVA, 132 KV Class
Maximum crane capacity 100 T
In house fabrication facilities for manufacturing tanks up to 20 MVA transformers



Testing

Electrotherm is recognized for its dynamic adaptation of technology through sheer flexibility in manufacturing operations. The world-class manufacturing and testing facilities are equipped with all requisite modern equipments for immaculate quality assurance. Each transformer undergoes all tests confirming to IS:1180, IEC 60076 Part 1-5 & 11 and IS:2026 by qualified and experienced engineers with precision grade instruments. Following tests are conducted:
Measurement of Voltage ratio
Measurement of Insulation Resistance
Measurement of No Load Losses and Magnetizing Current
Induced over Voltage Test
Checking of Vector Group and Polarity
Separate source High Voltage with Standing Test
Measurement of Load Losses and Impedance Voltage
Measurement of winding Resistance
Measurement of Zero Sequence Impedance
Temperature Rise Test Transformer tank
Pressure and Vacuum Testing of Transformer tank
Checking of Dielectric Strength of Transformer Oil
(Test Certificates are issued with each transformer)
^Top


Photo Gallery

Infrastructure Infrastructure

Infrastructure Infrastructure

Infrastructure Infrastructure

Infrastructure Infrastructure
